Automotive Diagnostics > Tachometers > SmarTach+ Digital Tachometer / Secondary Ignition Voltage Test

SmarTach+ Digital Tachometer / Secondary Ignition Voltage Tester

SmarTach+ Digital Tachometer / Secondary Ignition Voltage Tester

Wireless Digital Tachometer:

  • No sighting of rotating parts or hook-up required.
  • Works on DIS, Conventional, Magneto and most spark ignition system.
  • For 1 to 12 cylinders and 2 or 4 cycle engines.
  • Measures from 200 to 20000 RPM on a 4-1/2 digits LCD display.
  • Advanced microcontroller technology yields 0.5 % accuracy.

Digital Secondary Ignition Voltage Tester:

  • Instant digital readings from 0 to 40000 Volt.
  • Special antenna sensor allows quick hook-up to spark plug and ignition coil wires.
  • No ground wire connections required, for fast troubleshooting.
  • Multiple diagnostic applications are described in comprehensive User's Handbook (Included).

Simple to use:

Tachometer: Set the number of cylinders and cycles, extend the antenna and hold the instrument about a foot obove the ignition system. RPM is displayed.

Secondary Ignition Voltage Tester: Hook the antenna sensor over a spark plug wire or coil. Peak voltage of the ignition pulse in kilovolts is displayed.

Digital tachometer:

  • Tachometer Range: 200 to 19999 RPM.
  • # of Cylinders: 1,2,3,4,5,6,8,10 and 12.
  • Cycles: 2 and 4 Cycles Response Time: 1/2 Second.
  • Accuracy: ? 0.5%.
  • Spark Ignition System: Distributor, Magneto and D.I.S.

Secondary Ignition Voltage Tester:

  • Ignition peak voltage range: 0 to 39.9 Kvolt.
  • Response time: 0.5 Seconds.

Mechanical Specifications:

  • Dimensions: 2.75" W x 5.35" L x 1" D ( 69.9 x 135.9 x 25.4 mm ).
  • Power supply: 9 Volt alkaline battery. Duracell MN1604 (included ).
  • Battery life: Approx. 200 hours of operation.
  • Power saving: Auto power off.
  • Antenna: Collapsible 5 sections with sensor hook.
  • Display: Large 4-1/2 Digits LCD.
Sheffield Research TA100 SmarTach Plus Digital Tachometer/Secondary Ignition Voltage Tester

  • Shipping Weight: 1.55lbs
  • Manufactured by: Sheffield Research
  • Toolsource #: 58060
  • Manufacturers Part #: TA100
  • Also Known As: SFTA100, SHE-TA100, SHFTA100

We have 15 in stock

Inventory available from other suppliers, prices may be different

List Price: $162.00
You save: $20.48
$141.52
