Automotive Diagnostics > Breakout Box

  • 100-Pin Breakout Box
    100-Pin Breakout Box
    Manufacturers Part #: 3238
    Your Price: $537.67Includes Free Shipping
    OTC 3238 100-Pin Breakout Box Universal Breakout/Pinout Box with 100 test points.Used for vehicle diagnosis via voltage and resistance measurements.Not designed for signal injection.Expandable to 180-pin with No. 3238-UPD to handle future vehicle systems.Used in conjunction with Vehicle Adapter Cable (VAC). ...
  • 80 Pin Breakout Box Adapter 2006 C/K Truck
    80 Pin Breakout Box Adapter 2006 C/K Truck
    Manufacturers Part #: J-47275
    Your Price: $613.95Includes Free Shipping
    Applications: 2006 C/K Truck J-47275 adapts to the previously essential J-39700 Breakout Box and connects between the Transmission Control Module and vehicle harness. Using a Digital Multimeter the individual circuits can then be measured for voltage or resistance and the values compared to the vehicle specifications to isolate the faulty circuit and locate the problem component. Non-stock item, manufacturer drop ship; please email service@tools...
  • 80 Pin Universal Breakout Box w/ 60 Pin Adapter Cable Kit - Ford
    80 Pin Universal Breakout Box w/ 60 Pin Adapter Cable Kit - Ford
    Manufacturers Part #: 3232
    Your Price: $662.40Includes Free Shipping
    Breakout Box w/ 60 Pin Adapter Cable Kit Features: Ford EEC-IV kit includes 80-pin Universal Breakout Box (OTC #3226) & 60-pin Adapter Cable Kit, EEC-IV System (OTC #3226-04).Breakout box adapter cable kit for Ford automobile & light truck 1983 to current. ...
  • 80-Pin Expansion Panel for No. 3238
    80-Pin Expansion Panel for No. 3238
    Manufacturers Part #: 3238-UPD
    Your Price: $359.29Includes Free Shipping
    Expands the 100-pin No. 3238 with an additional 80-pin panel, resulting in a 180-pin No. 3239. (Must be used with No. 3238.) OTC 3238-UPD 80-Pin Expansion Panel for No. 3238 ...
  • Breakout Box - EEC-IV 60 Pin
    Breakout Box - EEC-IV 60 Pin
    Manufacturers Part #: 3225
    Your Price: $805.33Includes Free Shipping
    Breakout Box - EEC-IV 60 Pin Features: Used to completely test all 1983 & later EEC-IV vehicles.When used w/ all OTC multimeters, critical resistance & voltage measurements are easily accessible from all 60 electrical circuits of the EEC-IV system through the remotely located diagnositc breakout box.Weight: 7 lbs. 12 oz. ...
  • Breakout Box Adapter Allison 1000
    Breakout Box Adapter Allison 1000
    Manufacturers Part #: J-43799
    Your Price: $1,168.61Includes Free Shipping
    Applications: Allison 1000 J-43799 is used with J-39700 Break -Out box to diagnose the electrical operation of the Allison 1000 Automatic Transmission. Following available Service Information diagnostics, the transmission Control Module (TCM) harness is disconnected from the TCM, and J-43799 is installed between the harness and the TCM.The appropriate circuit can then be tested and measured at the corresponding terminal of the J-39700, per avail...
  • CAN Test Box CTB for Cars & Light Trucks
    CAN Test Box CTB for Cars & Light Trucks
    Manufacturers Part #: CTB-1005-3
    Your Price: $312.00Includes Free Shipping
    Many of today's workshops demand a device that helps them diagnose via the communication link, especially the latest CAN- Bus vehicles. When the scan tool fails to establish communication with a scan tool, the OBDII system seems not to respond, or a CAN-Bus system related fault code is registered, you need to begin testing at the communication link. The CAN Test Box (CTB) is a diagnostic tool which connects to a vehicle's OBDII connector and is u...
  • Harness for Allison 4th Generation 3000 4000 Transmissions
    Harness for Allison 4th Generation 3000 4000 Transmissions
    Manufacturers Part #: J-47279
    Your Price: $749.63Includes Free Shipping
    For 4th Generation Allison 3000/4000 series transmissions.This adapter harness is used with the J-39700 WTEC III Universal Breakout Box..The magnetic overlay, part number J-47279-1, can be ordered separately. Non-stock item, manufacturer drop ship; please email service@toolsource.com for cost and lead time before ordering. This is a non-quoted item and the price fluctuates; we have to get pricing each time an order is placed. Kent-Moore J-47279 ...
  • Inter-Connect Cable for Breakout Box - 10 Ft
    Inter-Connect Cable for Breakout Box - 10 Ft
    Manufacturers Part #: 3226-13
    Your Price: $180.26Includes Free Shipping
    Interconnect Cable for Breakout Box - 10 Ft Features: This 10 ft. cable replaces the 4 ft. cable that comes with the OTC #3226 Breakout Box.Allows the technician to hook up to the processor if it is underneath the hood for a vehicle road test.Weight: 1 lb. 8 oz. ...
