Battery and Electrical System Analyzer with Built In Printer



Midtronics | Battery and Electrical System Analyzer with Built In Printer | MDX-650P

The Midtronics MDX-650P Battery and Electrical System Analyzer with Built In Printer is a powerful and versatile tool that can be used to test batteries and electrical systems in a variety of vehicles. The MDX-650P is safe, fast, and simple to use, making it ideal for technicians of all levels.

Key Features:

  • Safe: The MDX-650P uses conductance technology to test batteries, which is safe to use even in the presence of flammable gasses.
  • Fast: The MDX-650P can test batteries and electrical systems in seconds, providing technicians with the information they need to make quick and accurate repairs.
  • Simple: The MDX-650P has a user-friendly interface that makes it easy to use, even for technicians who are new to battery testing.

Applications:

The MDX-650P can be used to test batteries and electrical systems in a variety of vehicles, including:

  • Automotive: The MDX-650P can test batteries and electrical systems in cars, trucks, vans, and SUVs.
  • Motorcycle: The MDX-650P can test batteries and electrical systems in motorcycles.
  • Marine: The MDX-650P can test batteries and electrical systems in boats and other marine vessels.
  • Lawn and Garden: The MDX-650P can test batteries and electrical systems in lawn mowers, tractors, and other lawn and garden equipment.
  • Group 31: The MDX-650P can test batteries and electrical systems in Group 31 batteries.
  • Commercial: The MDX-650P can test batteries and electrical systems in commercial vehicles, such as buses and trucks.
  • 4D/8D: The MDX-650P can test batteries and electrical systems in 4D and 8D batteries.

Benefits:

The Midtronics MDX-650P Battery and Electrical System Analyzer with Built In Printer offers a number of benefits to technicians, including:

  • Accurate: The MDX-650P provides accurate battery and electrical system test results, helping technicians to make quick and accurate repairs.
  • Portable: The MDX-650P is portable and easy to use, making it ideal for technicians who need to test batteries and electrical systems in a variety of locations.
  • Cost-effective: The MDX-650P is a cost-effective way to test batteries and electrical systems, helping technicians to save time and money.

Specifications:

  • Display: 5-line Text/Graphical Backlit Display
  • Operating Temperature: 0C to +50C (32F to +122F)
  • Test Range:
    • CCA: 100-2000 BY 5
    • CA: 100-2000 BY 5
    • MCA: 100-2000 BY 5
    • JIS#: By Part Number
    • EN: 100-2000 BY 5
    • DIN: 100-1200 by 5
    • SAE: 100-2000 by 5
    • IEC: 100-1200 by 5
  • Voltage Range: 1Vdc 30Vdc
  • Cable Length:
    • 4/ 122cm (MDX-640)
    • 10/305cm (MDX-650/650P)
  • Power Requirements: Uses the power of the battery under test and 6 AA Internal Batteries
  • Languages:
    • English
    • Spanish
    • French Canadian
    • Portuguese
  • Housing Material: Acid resistant ABS plastic
  • Dimensions: 27cm x 10cm x 5cm (10.6 x 3.9 x 2.4)
  • Weight: 771g (1.7lbs)

**To learn more about the Midtronics MDX-6

  • Model: 103858
  • Shipping Weight: 6.7lbs
  • Manufacturers Part #: MDX-650P
  • Manufactured by: Midtronics
  • Also Known As: MDMDX-650P, MIDMDX-650P, MDT-MDX-650P, MPMDX650P

Usually In Stock
Usually ships in 24-48 hours
Manufacturer Direct

$891.86
