Duramax LB7 Injector Puller

Duramax LB7 Injector Puller

Features and Benefits

  • Straight Pull easily removes carbon coated Duramax LB7 Injectors
  • Straight Pull reduces the possibility of pulling or loosening the injector sleeve
  • Fork tool separates the injector and sleeve after assembly has been pulled
  • Reduce redundant service times by up 1/2 hour per injector / sleeve assembly
  • Remove sleeve from injector without damage

The Duramax LB7 Injector Puller kit is designed to work on 2001 to 2004 LB7 Duramax Diesel engines.  Over time carbon forms around the injector tip ans sleeve.  Factory pullers pull at and angle causing the injector to bind in the sleeve.  This partially pulls or loosens the injector sleeve leaving the sleeve in the head requiring additional service procedures. The Schley injector puller pulls straight removing the injector and sleeve as an assembly. This reduces the potential of having to perform a second service procedure to remove the sleeve.  After the injector / sleeve assembly is removed use the injector / sleeve separator to safely remove the sleeve from the injector.


  • Shipping Weight: 3lbs
  • Manufactured by: Schley Products, Inc
  • Toolsource #: 187885
  • Manufacturers Part #: 11700
  • Also Known As: SCH11700, SL11700, SLY-11700

Only 1 left in stock - order soon
