ZAP-50 Series Turbo Pump 5,000 PSI - ZINKO Hydraulic Jack

Designed for increased flow rate and reduced pressure the Zinko Turbo series pumps are a perfect fit for applications requiring faster cycle times. Operate on shop air to drive a variety of single acting rams, presses and hydraulic pullers.

High Speed 5,000 psi. Air Hydraulic Pump 183 cuin Reservoir

Features:

• Design based on work proven ZAP series pump.
• High flow rate allows more work to be completed in less time, specifically designed for hydraulic equipment that requires quick cycle times and hydraulic pressure requirements up to 5,000 psi.
• Portable to any job site equipped with compressed air. Takes the place of manual pumps. Less operator fatigue, more productivity.
• Compact, light-weight design for easy handling and storage.
• Internal relief valve protects system components.
• Metal housing is extremely heavy duty, these pumps are durable and long lasting.
• Two-stage release mechanism for fast ram return while reducing hydraulic shock. Operates easily by hand or foot.
• All-metal air motor for reliability and easy maintenance.
• Operates at up to 5,000 psi (350 bar).

Specifications:

• Oil Capcity (in3): 183
• Pressure Rating: 5,000 psi
• Output Flow Rate (in3/min):
  • No Load: 133
  • Load: 18
• Air Pressure Range: 80-140 psi
• Oil Port: 3/8" NPT
• Shipping Weight: 27 Lbs.

Country of Origin: Taiwan

Zinko Hydraulic Jack ZAP-502 5,000 psi Turbo Series Pump
