Zap Series Single Stage Air Pump - 100 cu. in. - ZINKO Hydraulic Jack

The ZINKO Hydraulic Jack ZAP-101 Zap Series Single Stage Air Pump transforms ordinary shop air pressure into powerful hydraulic energy. Delivering up to 10,000 psi (700 bar) of hydraulic pressure, this versatile air pump is engineered for professional applications, providing efficient and controlled force while significantly reducing manual effort and operator fatigue for technicians and mechanics.

Key Features

• High-Efficiency Oil Flow: The ZAP-101 delivers superior oil flow, outperforming many competitors by as much as 2 to 1, enabling faster completion of tasks.
• Two-Stage Release Mechanism: Features a two-stage release for rapid ram return, effectively reducing hydraulic shock and extending the lifespan of connected components.
• Versatile Operation: Designed for convenient activation by either hand or foot, adapting to diverse working conditions and operator preferences.
• Durable Construction: Built with a reliable all-metal air motor for consistent performance and simplified maintenance, complemented by a heavy-duty anodized aluminum reservoir.
• Integrated System Protection: An internal relief valve is incorporated to safeguard system components from overpressure, enhancing both safety and tool longevity.
• Portable and Adaptable: Easily transported to any job site equipped with compressed air, and capable of connecting with 2 to 4 cylinders when paired with appropriate valves and accessories.

Applications

The ZINKO ZAP-101 is an indispensable tool for a wide range of automotive and industrial applications. It is ideally suited for tasks such as lifting heavy vehicle components, precise crimping, efficient pipe cutting, and various pulling applications. This air pump seamlessly powers hydraulic cylinders, small presses, and other hydraulic tools, making it a valuable asset for professional technicians and industrial mechanics seeking to enhance productivity and streamline operations.

Specifications

• Manufacturer: ZINKO Hydraulic Jack
• Model Number: ZAP-101
• Reservoir Usable Oil Capacity: 98 cu. in.
• Maximum Pressure Rating: 10,000 PSI (700 bar)
• Output Flow Rate (No Load): 77 cu. in./min
• Output Flow Rate (Load): 13 cu. in./min
• Operating Air Pressure Range: 40-140 psi (3-10 bar)
• Air Consumption: 10 Scfm
• Sound Rate: 85 dBA
• Oil Port: 3/8 NPTF
• Ship Weight: 21 Lbs
