CAN Test Box CTB for Cars & Light Trucks - Strategic Tools & Equipment

Specifications

• Model Number: CTB-1005-3
• Manufacturer: Strategic Tools & Equipment
• Weight: 2.7 lbs
• Connector Type: Standard 16-pin OBD2
• Operating Voltage: Designed for typical automotive 9V-18V DC systems
• Included: CTB-1005-3

Key Features

• OBD2 Port Breakout: Provides direct access to all 16 pins of the vehicle's OBD2 connector.
• Live Data Line Monitoring: Features LED indicators for real-time visualization of communication activity on various data lines, including CAN High and CAN Low.
• Power and Ground Verification: Displays the presence and integrity of power (pin 16) and ground (pins 4 & 5) connections.
• Individual Pin Access Points: Allows for easy connection of multimeters, oscilloscopes, or jump leads to any specific pin for detailed testing.
• Integrated Protection: Often includes an internal fuse to safeguard connected diagnostic equipment and the vehicle's electrical system.

Applications

• Automotive Diagnostics: Essential for initial diagnostic checks of communication protocols and electrical integrity in cars and light trucks.
• CAN Bus Troubleshooting: Used to identify and diagnose issues within the Controller Area Network (CAN) bus system.
• OBD2 Port Pre-Check: Verifies the health of the OBD2 data link connector before connecting expensive scan tools, protecting against potential damage.
• Electrical System Analysis: Facilitates testing power, ground, and data lines for shorts, opens, or incorrect voltage readings.
• Module Communication Testing: Aids in diagnosing communication problems between various electronic control modules (ECMs).

Benefits

• Streamlined Diagnostics: Simplifies complex automotive electrical and communication troubleshooting, leading to faster problem identification.
• Enhanced Equipment Protection: Safeguards expensive diagnostic scan tools from potential damage due to faulty vehicle wiring or power issues.
• Improved Accuracy: Provides clear visual feedback and physical access to data lines, enhancing the accuracy of diagnostic procedures.
• Time-Saving: Quickly isolates power, ground, and data line faults, significantly reducing diagnostic and repair times.
• Versatile Testing: Offers a comprehensive platform for various tests beyond what a standard scan tool can provide, supporting in-depth analysis.
