Mopar Essential Tools | 6979 | OBDII Breakout Box

Specifications

The Mopar Essential Tools OBDII Breakout Box {manufacturers_part_number} is designed for comprehensive automotive diagnostic applications. This tool provides access to all 16 pins of the vehicle's OBD-II Data Link Connector (DLC) for detailed electrical testing and signal monitoring. Its robust construction ensures durability in a professional workshop environment. The compact and lightweight design facilitates ease of handling and portability during diagnostic procedures.

Key Features

• 16-Pin Access: Directly connect and monitor all 16 pins of an OBD-II port. This feature allows technicians to individually probe and test each circuit for comprehensive diagnostics.
• Voltage and Ground Monitoring: Easily verify power and ground connections to the OBD-II port, ensuring proper functionality before connecting diagnostic scan tools.
• Protocol Identification: Aids in identifying communication protocols (e.g., CAN, K-Line, J1850) present on specific pins, crucial for advanced troubleshooting.
• Safe Probing: Provides a secure and isolated method to connect multimeters, oscilloscopes, or other diagnostic equipment, preventing damage to the vehicle's OBD-II port or wiring harness.
• Robust Connectors: Equipped with high-quality connectors designed for repeated use in demanding automotive settings.

Applications

The OBDII Breakout Box is an indispensable tool for automotive technicians, electricians, and diagnostic specialists. It is primarily used for:

• Troubleshooting OBD-II Communication Issues: Diagnosing problems with a vehicle's On-Board Diagnostics communication network, including issues with scan tool connectivity.
• Pin-Out Testing: Verifying the integrity and function of individual pins within the OBD-II DLC.
• CAN Bus Analysis: Monitoring and analyzing Controller Area Network (CAN) bus signals and data flow without direct splicing into vehicle wiring.
• Electrical System Diagnosis: Identifying short circuits, open circuits, and other electrical faults within the OBD-II system and related vehicle circuits.
• Scan Tool Verification: Confirming proper power and communication line functionality before using a more expensive scan tool, thereby protecting diagnostic equipment.

Benefits

• Enhanced Diagnostic Accuracy: Provides precise access to communication lines, allowing for more accurate and efficient identification of complex electrical and communication faults.
• Reduced Diagnostic Time: Streamlines the diagnostic process by offering a quick and direct method to test OBD-II port functionality and communication protocols.
• Protection for Vehicle and Equipment: Safeguards the vehicle's OBD-II port from potential damage caused by incorrect probing and protects sensitive scan tools from electrical spikes or misconfigurations.
• Versatile Troubleshooting: Supports a wide range of diagnostic tasks, from basic power checks to advanced CAN bus analysis, making it a valuable addition to any professional toolkit.
• Improved Workflow: Enables technicians to perform non-intrusive tests and monitor signals in real-time, improving the overall efficiency of vehicle repair and maintenance.
