Data Logging Video Borescope System - General Tools & Instruments

The General Tools & Instruments DCS1600 Data Logging Video Borescope System is a complete, portable, and robust inspection tool designed for professional technicians. This handheld system combines a high-resolution camera-tipped probe with a vibrant display and data logging capabilities, enabling detailed visual inspection and documentation in challenging environments. Its professional-grade construction and intuitive operation make it an essential asset for thorough diagnostic work.

Key Features

• High-Performance Imaging & Recording: Capture crisp still photos and dynamic video (VGA resolution for recording), viewable in real-time on a 3.5" extra-wide TFT monitor. Integrated SD memory supports extensive documentation and easy output via USB or TV.
• Flexible & Resilient Probe: Features a 3.3 ft (1m) long, 0.2" (5.5mm) diameter flexible-obedient probe that retains its shape. It is water, oil, dust, and scratch resistant (IP67) for reliability in harsh conditions.
• Optimized Illumination: Four super-strength white LED lights at the probe tip provide bright, adjustable illumination for clear visibility in dark areas.
• Versatile Viewing: Includes multiple mirrored viewing tips (30°, 45°, 60°) to offer expanded angles for inspecting off-axis targets.
• Extended Battery Life: Rechargeable Li-Polymer batteries deliver up to 4 hours of continuous recording, supporting prolonged inspection tasks.
• Durable Construction: Built with a rugged steel housing and protected by a heavy-duty waterproof blow-mold case, ensuring durability and easy transport.

Applications

Ideal for automotive and diesel maintenance, including engine cylinder inspection via spark plug holes, as well as checking for internal component wear or fluid leaks. Also vital for aircraft maintenance, industrial machinery, infrastructure assessment, and security applications requiring visual access to confined or hard-to-reach areas.

Specifications

• Probe Diameter: 0.2" (5.5mm)
• Probe Length: 3.3 ft (1m)
• Field of View (Diagonal): 56°
• Depth of Field (DOF): 0.4 to 2.4 in. (10mm to 60mm)
• Water Resistance: Insert tube only (IP67)
• Operating Temperature (Console): 0°C to 55°C (32° to 140°F)
• Display: 3.5" (89mm) TFT LCD QVGA (320x240 pixels)
• Recording Resolution: VGA (640x480 pixels)
• Battery Life: Up to 4 hours (Rechargeable Li-Polymer, 3.7V)
