Specifications
The JIMS USA Cam Gear Alignment Tool, model 1290, is engineered for precise cam gear installation and removal on compatible engines. It features robust construction designed for durability in professional workshop environments. The tool weighs approximately 3 pounds.
Key Features
- Precision Indexing: Accurately indexes cam gear position for consistent installation and removal processes.
- Adjustable Timing: Facilitates advancing or retarding cam gear position by up to 10 degrees, with an exactitude of 1/4 degree.
- Versatile Repositioning: Allows for the accurate positioning and repositioning of cam gears from one camshaft to another.
- Durable Construction: Built with high-quality materials to withstand demanding workshop conditions.
- Instructional Support: Includes a detailed instruction sheet for straightforward operation.
Applications
This cam gear alignment tool is specifically designed for use on all Harley-Davidson Single Cam Big Twin models produced between 1970 and 1999, which include Shovelhead and Evolution engines. It is essential for tasks involving the installation and removal of cam gears, ensuring proper fitment and timing. A shop press is required for both the removal and installation processes. The tool No. 1390 is recommended for cam gear removal.
Benefits
- Enhanced Accuracy: Improves the precision of cam gear installation and removal, reducing errors.
- Optimal Engine Performance: Ensures precise camshaft timing, which is critical for achieving optimal engine performance.
- Reduced Damage Risk: Minimizes the potential for damage to cam gears and camshafts during servicing.
- Time and Cost Efficiency: Streamlines the camshaft installation process, saving valuable time and reducing the need for repeated adjustments.
- Professional Results: Delivers the accuracy and reliability necessary for professional-grade engine work.
- Preserves Gear Fit: Helps maintain the correct cam gear to pinion gear fit during installation.
