Pilot Vacuum Gauge - Inficon

The Inficon Pilot Vacuum Gauge (Model 710-202-G1) provides accurate, real-time vacuum measurement for professional automotive and industrial refrigeration and air conditioning systems. Utilizing advanced Pirani sensor technology and a durable 1/4" stainless steel refrigeration fitting, this digital gauge delivers precise readings across the entire evacuation cycle, from atmospheric pressure down to 1 micron. Its clear digital display ensures technicians can monitor vacuum levels and identify potential leaks immediately.

Key Features

• Wide Measurement Range: Accurately measures vacuum levels from 760,000 microns (atmosphere) down to 1 micron, critical for thorough system evacuation.
• Multi-Unit Display: Easily switch between microns, Pascal, and millibars to suit specific job requirements or regional standards.
• Instant Leak Detection: The continuous display of actual vacuum levels throughout the evacuation process allows for immediate identification of leaks.
• Durable Construction: Equipped with a professional-grade 1/4" stainless steel refrigeration fitting designed for demanding applications.
• Convenient Operation: Features automatic shut-off to conserve battery life and stores the last reading for quick reference upon restart.
• Extended Warranty: Backed by a 2-year over-the-counter warranty for reliable performance and peace of mind.

Applications

The Pilot Vacuum Gauge is an essential tool for technicians performing maintenance, repair, and installation on air conditioning and refrigeration systems in automotive, commercial, and industrial settings. It is compatible with any size vacuum pump and ensures precise monitoring of the evacuation process, guaranteeing optimal system performance and longevity.

Specifications

• Weight (with Battery): 7.25 oz (0.2 kg)
• Power Source: 9-volt battery
• Refrigeration Fitting: 1/4" male flare
• Controls: On/Off/Unit Selection Button
• Display Units: microns, Pascal, millibars
• Display Range: atm (760,000 microns) to 1 micron
• Auto Shut-off: After 15 minutes; last reading displayed when restarted
• Accuracy: < 20,000 microns ± 5%, > 20,000 microns ± 10% of reading
• Resolution: 1-micron increments (microns); 1-Pa increments (Pascal); 0.01-mbar increments (mbar)
• Operating Temperature Range: 0 to 50 °C
• Storage Temperature Range: -10 to 60 °C
• Maximum Overpressure: 150 psi (7.76 x 10^6 microns)
