Specifications

The Makita MAC2400 is a 2.5 HP Big Bore™ Air Compressor engineered for demanding job site performance and durability. This twin stack unit features a robust oil-lubricated pump and motor, designed for efficient and quiet operation.

• Manufacturer: Makita
• Model Number: MAC2400
• Product Name: 2.5 HP Big Bore™ Air Compressor (Twin Stack)
• Motor: 2.5 HP (4-Pole), 120V, 60 Hz, 12.3 Amps
• Tank Capacity: 4.2 gallons (Twin Stack)
• Maximum Operating Pressure: 130 PSI
• Air Delivery (90 PSI): 4.2 CFM
• Air Delivery (40 PSI): 4.8 CFM
• Pump Type: Oil-Lubricated, Cast Iron Big Bore™
• Pump Speed: 1,730 RPM (lower speed for reduced noise and wear)
• Noise Level: 79 dB(A)
• Net Weight: 77 lbs
• Shipping Weight: 86.3 lbs
• Dimensions (L x W x H): 20.5 x 20.5 x 19.5 inches

Key Features

• Big Bore™ Engineered Pump: Equipped with a cast iron cylinder and piston, this design offers increased bore and stroke, contributing to faster recovery and enhanced compression.
• Oil-Lubricated System: The pump is oil-lubricated to ensure cooler operation, reduce wear on components, and minimize operational noise levels.
• Low AMP Draw Motor: The 4-pole motor features a low amperage draw, which helps reduce instances of tripped breakers during startup and mitigates voltage drops that can lead to premature motor failure.
• Roll-Cage Construction: A protective roll bar handle and cage construction surround the unit, providing comprehensive protection to withstand the demands of harsh job site conditions and ensuring portability.
• Dual Universal Quick Couplers: Features two 1/4-inch universal quick couplers, allowing for the simultaneous use of multiple pneumatic tools.
• Efficient Heat Dissipation: Finned discharge tubing is integrated to dissipate heat more effectively, helping to reduce moisture buildup in the tank.
• Convenient Maintenance Features: Includes an accessible oil drain, an oil sight glass for easy monitoring, and a tank drain valve designed for simpler maintenance.

Applications

The Makita MAC2400 is well-suited for a variety of tasks requiring consistent and reliable air power, from professional construction to workshop projects.

• Framing and Trim Nailing: Delivers ample power for two nailers simultaneously, making it suitable for framing, roofing, and finish carpentry tasks.
• General Workshop Use: Powers a range of pneumatic tools for various projects in a garage or workshop setting.
• Automotive Work: Capable of operating most automotive air tools, such as impact wrenches for lug nuts.
• Job Site Operations: Engineered for tough job site conditions, providing industrial power and durability for diverse construction applications.

Benefits

• Enhanced Tool Performance: The Big Bore™ pump design ensures faster recovery times, allowing tools to operate efficiently with sustained power.
• Extended Motor and Pump Life: Running at a lower RPM and featuring an oil-lubricated, cast iron pump, the compressor experiences less wear, resulting in increased longevity.
• Quieter Work Environment: Operating at 79 dB(A), this air compressor provides a quieter experience compared to many competitive units, reducing noise disruption on the job site or in a workshop.
• Reliable Operation: The low AMP draw minimizes electrical disruptions, while thermal overload protection safeguards the motor from heat damage, ensuring consistent and dependable performance.
• Improved Job Site Durability: Heavy-duty cast iron construction and a protective roll-cage design allow the compressor to endure rigorous daily use and harsh environments.
• Simplified Maintenance: Features like the oil sight glass and easy-access drain valve streamline routine maintenance, promoting optimal performance and extending service intervals.
