Mini Fluid Evacuator

Operates on compressed air to create a powerful venturi vacuum for quickly evacuating small reservoirs. The lid unthreads for convenient emptying, and the evacuation hose is perfect for getting into those hard to reach places.

  • Compressed air operation.
  • Integrated 1.9 quart (1.8 liter) capacity reservoir.
  • Variable control thumb throttle.
  • Swivel air inlet.
  • Quiet, muffled exhaust.
  • Automatic overflow prevention.

Includes:

  • Fluid evacuator.
  • 4 ft (1.2 m) fluid evacuation hose.
  • Molded base w/ screws for bench mounting.
  • Hanging hook.
  • User manual (English/French/Spanish/German).

Specifications:

  • Reservoir Capacity: 1.9 quarts (1.8 liters).
  • Working Pressure: 60-150 psi.
  • Vacuum @ 90 psi (6.2 bar): 26 in. Hg (88 kPa).
  • Air Consumption @ 90 psi (6.2 bar): 4.3 cfm.
  • Flow Rate @ 60 psi (4.1 bar): 50 oz/min.
  • Inlet Thread Size: 1/4" NPT.
  • Packaged Weight: 4.8 lbs.
  • Size: 9" tall x 6.5" dia.

Mityvac MV7430 Mini Fluid Evacuator

  • Model: 97223
  • Shipping Weight: 3.9lbs
  • Manufacturers Part #: MV7430
  • Manufactured by: Mityvac
  • Also Known As: MITMV7430, NEMV7430, MTY-MV7430

We have 45 in stock

$165.37
