3/4 In Dr Computorq II 60-600 ft-lbs - CDI Torque Products

The COMPUTORQ II is our state-of-the-art Digital Programmable Torque Wrench. It has many applications, including precision torquing of critical fasteners, tracking applied torque for quality control testing, as well as destructive component testing. The Computorq II is easy to program using the soft touch keypad. Simply program a "target" torque including upper and lower limits, and the wrench will signal with a beep when that torque setting is reached. If the user exceeds the target torque, an alarm tone sounds and the red light flashes. Computorq II is available in six models with ranges from 5 in. lbs. up to 1000 ft. lbs.

Features:

• Up to 4000 torque values can be stored in memory
• Downloading capability to a printer/ computer datalogger via RS232
• Selectable modes of operation are "Peak Hold" and "Track"
• Target torque values are easily programmed and viewed through the keypad
• A 9v alkaline battery is standard for 60 hours of operation
• Accuracy: ? 1% of indicated value, CW & CCW, from 20% to 100% of full scale; ? 1%, plus 5 increments from 10% to 20% of full scale
• All calibration data is stored in the microprocessor
• Selectable baud rate for downloading to a printer/computer/datalogger
• Options are 300, 600, 1200, 2400, 4800, 9600, or 19200

• Torque Range - Increment:
  • 720 - 7200 in. lb. - 3 in. lb.
  • 60 - 600 ft. lb. - .2 ft. lb.
  • 810 - 8130 dNm - .1 ft. lb.
  • 81 - 813 Nm - .1 Nm
  • 830 - 8300 cmkg - 4 cmkg
  • 8.3 - 83 mkg - .01 mkg
• Length: 46.5" (1181mm)
• Weight: 9.5 Lbs. (4.3 Kg)
