Carbon Pile Load Tester 500 AMP - Associated Equipment

The Associated Equipment Model 6034 Carbon Pile Load Tester is a robust, professional-grade diagnostic tool engineered for accurate assessment of 6-volt and 12-volt automotive and industrial batteries. Designed for technicians requiring dependable performance, this variable load tester quickly identifies battery health, cranking capabilities, and potential electrical system issues. Its straightforward operation and durable construction make it an essential addition to any professional workshop.

Key Features

• Versatile Battery Compatibility: Effectively tests both 6-volt and 12-volt lead-acid batteries, accommodating a wide range of vehicles and applications.
• Clear Analog Displays: Equipped with two large 4.5" analog meters for precise and easy-to-read ampere (0-500A) and voltage (0-16V DC) measurements.
• Precision Load Control: Features a manual adjustment knob for fine-tuning the carbon pile load, ensuring accurate and controlled testing.
• Integrated Safety Timer: A built-in buzzer sounds after 15 seconds of load engagement, preventing over-discharge and ensuring consistent test durations.
• Professional-Grade Leads and Clamps: Comes with 2.5-foot, 4 AWG DC test leads and heavy-duty 400A safety clamps for secure and reliable connections.

Applications

This carbon pile load tester is ideal for professional technicians performing comprehensive battery and electrical system diagnostics. It is suitable for testing batteries in passenger vehicles, light trucks, motorcycles, marine applications, and various industrial equipment. Use it to diagnose weak batteries, evaluate alternator performance under load, and troubleshoot starter draw issues in a professional setting.

Specifications

• Manufacturer: Associated Equipment
• Model Number: 6034
• Load Capacity: 500 Amps
• Ammeter: 4.5" (0-500 A)
• Voltmeter: (0-16 V DC)
• Test Leads: 2.5 ft, 4 AWG cable
• Clamps: 400 A Safety Clamps
• Limited Warranty: 90 Days
• Shipping Dimensions (HxWxD): 7" x 12.5" x 11"
• Weight: 10 lbs.
