EZ-Scan 5000 Scan Tool - CANOBD Coverage - OBD I & OBD II - Auto Xray

The Auto Xray EZ-Scan 5000 is a professional-grade diagnostic scan tool designed for comprehensive automotive troubleshooting. It offers extensive coverage for both OBD I and OBD II vehicle systems, including support for all OBD II protocols, such as the Controller Area Network (CAN) protocol. This robust tool provides technicians with the capability and flexibility needed to efficiently manage complex diagnostic processes across a wide range of vehicles.

Key Features

• Broad Vehicle Compatibility: Supports domestic OBD I vehicles from 1982 (GM), 1983 (Ford, Chrysler), and 1991 (Jeep), along with OBD II compliant vehicles from 1996 to the current year, including Asian and European models.
• Comprehensive Code Reading: Collects valuable data from a vehicle's on-board computer, supporting multiple trouble code requests including generic (mode 3), pending (mode 7), and enhanced codes (mode 13).
• On-Screen Definitions: Provides on-screen definitions for OBD I trouble codes, as well as generic and manufacturer-specific OBD II codes, streamlining the diagnostic process.
• Live Data Monitoring: Features live data stream monitoring with a 29-frame capture mode, allowing technicians to analyze vehicle performance and set capture intervals from 500ms to 5000ms.
• Advanced Diagnostic Functions: Detects OBD-II freeze frame information, displays readiness test status, O2 sensor test results, and vehicle ID (mode 9), assisting in thorough system analysis.
• Durable and User-Friendly Design: Built with a Dupont Super Tough 901 Nylon Case and a durable, spill-proof membrane keypad, it features an 8-line, 128 x 64 pixel backlit display with 32-step contrast control for clear visibility in various working conditions.

Applications

The Auto Xray EZ-Scan 5000 is an essential tool for professional technicians and mechanics performing diagnostics, maintenance, and repair. It is ideal for identifying check engine light issues, analyzing sensor performance, verifying emission system readiness, and troubleshooting both older and modern vehicle systems with its extensive OBD I and OBD II capabilities. The tool's internet upgradeability ensures ongoing compatibility with new vehicle technologies.

Specifications

• HARDWARE:
  • Display: 8 Line Display, 128 x 64 Pixel Screen
  • Ports: 8 Pin AMP OBD Communications Port, 8 Pin RJ45 Serial Communications Port
  • Display Features: Backlit Display, 32 Step Contrast Control Display
  • Power: Battery Powered (4 AA)
  • Additional Features: Data Save, Auto Off, Dual Processor System, Real-Time Operating System, Flash Updateable Applications, Software Configurable Hardware
  • Construction: Dupont Super Tough 901 Nylon Case, Durable Spill-proof Membrane Keypad
• SOFTWARE:
  • OBD-I Domestic Support: GM 12 & 16 pin ALDL, Ford - EEC IV, Chrysler - SCI
  • OBD-II Protocol Support: CAN, VPW, PWM, 9141, Keyword 2000
  • Code Support: OBD-II Generic, OBD-II Manufacturer Specific
