GPC 2150 - Welder, AC Generator & Air Compressor - Goodall Manufacturing

The Goodall Manufacturing GPC 2150 is an all-in-one power center designed to meet the demanding needs of professional mobile service mechanics and technicians. This robust unit integrates a DC stick welder, AC generator, and a two-stage air compressor into a single, compact footprint, significantly reducing the space required in service vehicles by up to 50%. Powered by an air-cooled Kohler Command OHV V-Twin engine with electric start, the GPC 2150 delivers reliable performance for a variety of on-site tasks.

Key Features

• Integrated Auto Idle: Automatically idles the engine down when not under load, contributing to fuel efficiency and reduced wear.
• DC Stick Welder: Offers a welding range of 40-250 amps, with a 225 amp 60% duty cycle, complete with 25 ft. of 1/0 gauge welding cables.
• AC Generator: Provides 5000 watts of continuous 60 Hz power (when not welding) through a synchronous, brushless AC generator. Outlets include one 120-volt, 20-amp duplex; one 120-volt, 30-amp twist lock; and one 240-volt, 20-amp twist lock.
• Two-Stage Air Compressor: Delivers 24 CFM at 100 PSI with a 150 PSI maximum pressure, featuring an air gauge on the control panel for tank pressure monitoring.
• Remote Mount Control Panel: The plug-and-play control panel can be easily mounted remotely, requiring an extension harness for distances beyond 12 inches.

Applications

The GPC 2150 is engineered for versatility, making it an essential tool for various mobile service applications. It is well-suited for government and municipal fleets, light to heavy-duty vehicle and equipment maintenance, on-site service and repair operations, and the equipment rental industry. Its compact design and multi-functionality make it ideal for integration into service trucks, pickup trucks, flatbeds, and tow trucks, providing on-demand power for a wide range of repair and maintenance tasks.

Specifications

• Dimensions (with fuel tank): 20" W x 53.5" D x 25" H
• Weight: 640 lbs.
• Footprint (without fuel tank and control box): 20" W x 48" D
• Control Box Dimensions: 18" W x 5" D x 12" H (bottom of unit to bottom of control box is 12")
