Truck Wheel Balancer - Single Phase - Coats fmr. Ammco-Coats / Hennesy

The Ammco-Coats 6401-1 Truck Wheel Balancer is engineered for the rigorous demands of professional automotive and industrial settings, providing precise balancing for a wide range of heavy-duty applications. This single-phase unit features an exclusive direct-drive power system with minimal moving parts, ensuring long-term accuracy and durability. It efficiently handles tires up to 46 inches in diameter and 18 inches wide, making it a reliable addition to any professional shop.

Key Features

• Direct-Drive Precision: Utilizes a robust direct-drive system with only one moving part, delivering highly accurate and consistent balancing results while minimizing maintenance requirements.
• Versatile Balancing Modes: Capable of balancing heavy-duty, RV, and light truck tires using dynamic, static, and dedicated RV balancing modes for comprehensive service.
• Intuitive User Interface: Features large dial indicator knobs for data entry and bright LED displays that clearly indicate weight locations and amounts, simplifying the balancing process.
• Optimized Efficiency: Achieves an average cycle time of just 12 seconds for truck tires, significantly enhancing shop productivity and throughput.
• Integrated Safety Measures: Equipped with a fully interlocked hood guard and an emergency stop button to ensure operator safety during operation.
• Streamlined Operation: Includes an automatic hub nut loosening feature and a movable stub shaft to facilitate quicker tire mounting and dismounting.

Applications

This heavy-duty truck wheel balancer is an ideal solution for commercial truck service centers, fleet maintenance operations, and busy repair shops handling a diverse range of vehicles. It is designed to accurately balance tires for commercial trucks, recreational vehicles (RVs), and light-duty trucks, accommodating the varied sizes and weights encountered in professional environments. The Ammco-Coats 6401-1 supports consistent performance and extended tire life for heavy-duty applications.

Specifications

• Tire Diameter: Up to 46 inches
• Rim Width: 4.5 inches to 18 inches
• Rim Diameter: 16 inches to 26 inches
• Maximum Tire Weight: 350 lbs.
• Resolution: ±0.01 oz., ±1.4 degrees
• Accuracy: ±0.5 oz in truck mode, ±0.1 oz in car mode
• Motor Rated Speed: 850 RPM
• Power Requirements: 220 VAC, 50/60 Hz, 1 Phase, fused @ 30 amps
