Transmission Jack 1000 Lb Capacity

Air or manual foot operated, two-stage ram frees both hands for easier alignment of automotive, van, and light truck transmissions, transfer cases or differentials in under hoist applications.

  • Universal head provides forward, back and side tilt
  • Fully-adjustable universal saddle with spring-loaded corner brackets for easy "tool-free" adjustment
  • 90-120 PSI air pressure required; 7-7/8 cu. ft./min. air consumption
  • Use this jack to remove and install fuel tanks by ordering AFF Fuel Tank Adapter #3198 (sold separately)

Specifications:

  • Capacity: 1,000 lbs.
  • Base Dimension: 38" x 38"
  • Head Length: 9"-20"
  • Head Width: 7"-22"
  • Right Tilt: 12?
  • Left Tilt: 12?
  • Rear Tilt: 46?
  • Forward Tilt: 42?
  • High Height: 73-1/2"
  • Low Height: 38"
  • Ram Stages: 2
  • Ship weight 218 lbs.

$85 standard freight fee. Applies to direct shipping points within the 48 continental US states. Rural Area Surcharge may apply.

  • *An additional $40.00 will apply to all residential deliveries of heavy-equipment.
  • *For lift-gate service, add $135.00.

Manufacturer drop ship.

American Forge & Foundry AFF 3192A 1000 Lb Capacity Transmission Jack

  • Model: 139277
  • Shipping Weight: 218lbs
  • Manufacturers Part #: 3192A
  • Manufactured by: American Forge & Foundry
  • Also Known As: AFF3192A, INT3192A

$1,163.30

This product has been discontinued

This product was added to our catalog on Wednesday 05 September, 2012.
