Atlas TC755 Tire Changer & WB49-2 Wheel Balancer Combo - Atlas Automotive

Specifications

• Manufacturer: Atlas Automotive
• Model Number: TCWB-COMBO3
• Product Name: Atlas TC755 Tire Changer & WB49-2 Wheel Balancer Combo
• Weight: 1000 lbs

Atlas TC755 Tire Changer:

• External Rim Clamping: 11 7/8" - 28" (three positions)
• Internal Rim Clamping: 13 7/8" - 29 7/8" (three positions)
• Maximum Tire Diameter: 47 1/2"
• Maximum Wheel Width (Bead Breaker): 18"
• Bead Breaker Force: 5,500 lbs.
• Air Requirement: 90-110 PSI
• Operating Voltage: 110V

Atlas WB49-2 Wheel Balancer:

• Maximum Tire Diameter: 39"
• Rim Size Range: 10" - 32" (for cars and light trucks)
• Rim Width: 1 1/2" - 20"
• Maximum Wheel Weight: 150 lbs.
• Balancing Accuracy: 1 gram
• Balancing Speed: 150 RPM
• Operating Voltage: 110V

Key Features

• Tilt-Back Column Tire Changer: The TC755 features a tilt-back column design, facilitating quicker and easier mounting and demounting of tires.
• Rim-Clamp Design: Securely holds various wheel types with a rim-clamp style, protecting surfaces with standard plastic inserts.
• Integrated Bead Blaster: A powerful built-in Bead Blaster system on the TC755 aids in seating stubborn or stiff sidewall tires.
• Pneumatic Locking Head: The TC755's pneumatic locking mount/demount head reduces movement during operation, enhancing precision and safeguarding rims.
• Versatile Jaw Positions: The TC755 includes adjustable jaws with three positions, enabling a wide range of clamping for diverse tire and rim sizes.
• Automatic 2D Data Entry: The WB49-2 automatically enters offset and diameter measurements using an inner measuring gauge, streamlining the balancing process.
• Split-Weight Function: The WB49-2 offers a Split-Weight Function, allowing weights to be discreetly hidden behind spokes for a clean wheel appearance.
• Automatic LED Rim Light: An automatic LED light on the WB49-2 illuminates the inside of the rim, improving visibility for accurate weight placement.
• Self-Calibration and Self-Diagnosis: The WB49-2 is equipped with self-diagnosing and self-calibrating capabilities, ensuring consistent accuracy and simplified maintenance.
• Static and Dynamic Balancing Modes: The WB49-2 provides both static and dynamic balancing modes to accurately address various wheel imbalance types.

Applications

This combo package is designed for professional automotive service environments, including:

• Commercial car repair shops
• High-volume tire service centers
• Large car dealerships
• Fleet maintenance operations
• Garages handling a broad spectrum of passenger car and light truck wheels

Benefits

• Boosted Operational Efficiency: Combines tire changing and wheel balancing into a single, cohesive system, significantly reducing service time and increasing vehicle throughput.
• Precision and Performance: The WB49-2's advanced features, such as automatic data entry and 1-gram accuracy, deliver superior wheel balance, reducing vibrations and extending tire life for a smoother ride.
• Expanded Service Capabilities: Handles a diverse range of tire and rim sizes, from 10-inch to 32-inch rims and tires up to 47 1/2 inches in diameter, allowing shops to service more vehicle types, including challenging low-profile and run-flat tires.
• Enhanced User Experience: Features like the TC755's tilt-back column and the WB49-2's easy-to-read LED display and automatic rim illumination simplify operation and minimize operator fatigue.
• Protection for Wheels: The TC755's protective jaw covers and pneumatic locking head work to prevent scratches and damage to expensive rims during the tire mounting and demounting process.
• Reliable and Durable: Engineered for the demands of commercial use, these machines offer robust construction and self-diagnostic functions for long-term dependability and reduced downtime.
