12 Channel Temperature Recorder w SD Card - General Tools & Instruments

Name: 12 Channel Temperature Recorder w SD Card
Brand: General Tools & Instruments
SKU: 121201
Price: 999.95 USD
Availability: LimitedAvailability

Part #: DT4208SD

larger image

Accurately Measures 12 Channels of Temperature from -148? to 3092° (-100? to 1700°)

This instrument's unique feature is its patented technique for storing sampled data in Excel format on removable SD memory cardsApplications:

Food and chemical processing
PC board burn-in
Paper production
HVAC/R (heating, ventilation and air-conditioning/refrigeration)
Power generation

Included Accessories:

Hard carrying case
Two Type K beaded thermocouple probes
2 GB SD memory card
User's manual

Optional Accessories:

9VDC adapter for 110V power supply (General P/N AC1)
Type K thermocouples
- General P/N TPK500 (-50? to 500°)
- General P/N TPK05 (-40? to 562°)
- General P/N TPK03 (-40? to 950°)

Specifications:

Embedded Microcontroller: Custom one-chip LSI device
Display Type: LCD with green backlight
Display Size: 2.05 x 1.5 in. (52 x 38mm)
Parameter Measured: Temperature (in ° or °)
Measurement Range:
- Using supplied Type K thermocouples: -148? to 2372° (-100? to 1300°)
- For other thermocouples: depends on type
Measurement Accuracy: For supplied Type K thermocouples: ? (4 % of reading + 2.0° max)
Measurement Resolution: For supplied type K thermocouples: 0.1? (F or C) below 1000°, 1? (F or C) above 1000°
ata Logging Sampling Time: 1 second to 1 hour
Settable Parameters: Date, time, decimal point or comma decimal division, auto power off, beep sound, loop recording enable or disable, temperature unit, sampling time
Storable/Recallable Readings: Maximum, minimum SD Card Capacity: 1 GB to 16 GB
Operating Temperature: 32? to 122° (0? to 50°)
Operating Relative Humidity: 0 to 85%
Power Supply: Six Alkaline "AA" batteries or optional 9-VDC AC adapter
Power Consumption:
- 7.5 mADC (normal operation, with backlight off and SD card not saving data)
- 25 mADC with backlight on and card saving data
- 36 mADC with backlight on and card saving data
Dimensions: 8.86 x 4.92x 2.52 in. (225 x 125 x 64mm)
Weight: 2.1 lb. (944g)

All returns on General Tools & Instruments products have a 20% restock fee.

General Tools & Instruments DT4208SD 12-Channel Temperature Recorder with Excel-Formatted Data Logging SD Card

Usually In Stock Usually ships in 24-48 hours Manufacturer Direct
