sup Car Storage Lift - 7,000 Lb - Bend-Pak

The Bend-Pak PL-7 Car Storage Lift provides a robust and efficient solution for professional automotive shops and serious enthusiasts requiring additional vehicle storage capacity. Engineered for durability and consistent performance, this 7,000 Lb capacity lift is designed to maximize vertical space within your facility, accommodating a wide range of passenger vehicles and light trucks. Its freestanding design offers installation flexibility, suitable for typical parking surfaces without extensive site preparation.

Key Features

• Independent Lifting Structures: Facilitates staggered offset installation, optimizing space utilization in multi-bay configurations.
• Weatherproof Electrical Connections: NEMA-rated connections effectively seal out water and dirt, ensuring reliable operation in diverse workshop environments.
• Galvanized Drip-Proof Platform: Protects the vehicle parked beneath from fluid drips and debris, maintaining cleanliness and preventing potential damage.
• Automatic Safety Locks: Features ten lock positions spaced 3 inches apart on each column, providing secure vehicle placement at various working heights.
• Low Maintenance Design: Equipped with maintenance-free composite carriage bearings and self-lubricating chain rollers, reducing the need for frequent servicing.
• Versatile Installation: Designed with a wide base-plate that mounts directly on grade, including asphalt surfaces, eliminating the need for special concrete footings.

Applications

The Bend-Pak PL-7 is an ideal asset for professional auto repair shops, detailing centers, and private collectors seeking to optimize their workspace. It allows technicians to efficiently store vehicles, freeing up valuable floor space for ongoing repairs, diagnostics, or other workshop activities. Its sturdy construction and high capacity make it suitable for long-term vehicle storage or for temporary staging during busy periods.

Specifications

• Lifting Capacity: 7,000 lbs (3175 kg)
• Maximum Wheelbase: 145" (3683 mm)
• Lock Positions: 10
• Bottom Clearance (First Lock Position): 45" (1143 mm)
• Inside Columns: 95" (2413 mm)
• Height Overall: 119-1/2" (3035 mm)
• Rise Overall: 73" (1854 mm)
• Bottom Leg Length: 144" (3658 mm)
• Width Overall: 103-1/2" (2629 mm)
• Platform Width: 88"
• Length Overall: 165" (4191 mm)
• Motor: 1 to 5 H.P. (Please indicate preferred voltage upon order: 110-440 Volts, single or three-phase)
• Time To Full Rise: 30-90 Seconds (depending on motor option)
