Electronic Specialties | 304B | Fuse Buddy Tester - ATC Blade

Specifications

The Electronic Specialties 304B Fuse Buddy Tester is designed for precise current measurement in ATC blade fuse circuits. It weighs 0.25 lbs and has compact dimensions of 7 x 1.5 x 1 inches, making it a portable and convenient diagnostic tool. This tester is capable of measuring current draws up to 20 amps at 48V DC, offering a resolution of 0.01A (10 milliamps) for detailed readings.

Key Features

• Direct ATC Blade Fuse Compatibility: Plugs directly into ATC blade fuse sockets, simplifying the connection process.
• In-Line Circuit Protection: The original fuse is inserted into the tester, maintaining circuit protection throughout the diagnostic procedure.
• Accurate Amperage Measurement: Provides precise digital readings of circuit amperage draw up to 20 amps.
• User-Friendly Design: Shaped like a fuse for easy and secure insertion into the fuse box, preventing clumsy connections.
• Compact and Durable: Constructed for reliability in demanding automotive environments, with a portable form factor for easy handling and storage.

Applications

The Fuse Buddy Tester - ATC Blade is an essential tool for automotive electrical troubleshooting and diagnostics. It is widely used for:

• Vehicle Electrical Diagnostics: Quickly identifies circuit amperage draw to pinpoint electrical faults.
• Parasitic Drain Testing: Effectively measures current draw when the ignition is off, helping to locate unexpected battery drains.
• Component Testing: Verifies the current consumption of individual electrical components and accessories.
• Troubleshooting Blown Fuses: Helps determine why a fuse is blowing by revealing excessive current draw on a circuit.
• Professional and DIY Use: Suitable for both professional automotive repair shops and enthusiasts performing vehicle maintenance.

Benefits

• Streamlined Diagnostics: Saves significant time and effort by providing direct, in-line current measurements, eliminating the need for complex setups.
• Enhanced Accuracy: Delivers precise amperage readings, crucial for accurately diagnosing intermittent electrical issues and verifying circuit integrity.
• Maintained Circuit Safety: Ensures continuous circuit protection during testing, preventing potential damage to vehicle electrical systems.
• Simplified Troubleshooting: Offers an intuitive and easy-to-use method for identifying electrical problems directly at the fuse box.
• Increased Efficiency: Allows technicians and DIYers to quickly isolate and resolve electrical faults, improving overall productivity.
