Brake Lathe Drum and Rotor - Coats fmr. Ammco-Coats / Hennesy

The Combination Lathe with the Right Combination of Speed and Value

AMMCO`s new Model 3860 brake lathe is for shops that need speed, disc/drum versatility, and low maintenance operation.This is a new design that incorporates many "Voice of the Customer" features that shops have told Ammco they wanted to see in a lathe. Ammco listened, and they built a brake lathe that works for a broad range of businesses.

The Model 3860 lathe features negative rake tools that greatly increases the life of cutting bits. A new chip diversion guard system keeps metal shavings out of the operating mechanisms of the unit, stopping hang-ups and cutting maintenance. The 3860 has been designed for faster setup between drum and rotor operation, and easier drum machining.

Max. Rotor Diameter 21.5"

Max. Rotor Face Width 4.5"

Max. Rotor Thickness 1.75"

Drum Capacity (Diameter) 6"-28"

Flywheel Diameter Flat or Stepped Up to 21.5"

Flywheel Face Width 4.5"

Spindle Speed 190 RPM

Rotor Feed Rate .0013"/REV

Drum Depth Up to 6.875"

Drum Feed Rate 0026"/REV

Motor 1 HP

Shipping Weight 552 Lbs.

Warranty 1 Year

**NOTE - This model (3860B) requires one of the following Adapter Kits at an additional cost. Select the kit that best fits your shops needs.

Click below for Adapter Kits.

GOOD: Hub & Hubless Adapters for Most Cars
BETTER: Hub & Hubless Adapters for Cars and Trucks thru 1/2 Ton
BEST: Hub & Hubless Adapters for Cars & Trucks thru 1 Ton

$85 standard freight fee.

Ammco-Coats 3860B Brake Lathe Drum and Rotor
