#804 EZ Test 10 Pc Back Probe Kit - Electronic Specialties

The Electronic Specialties #804 EZ Test 10 Pc Back Probe Kit is an essential tool for professional technicians and mechanics requiring precise electrical circuit testing. This comprehensive kit provides a versatile array of back probes and alligator clips, designed to facilitate accurate diagnostics across automotive, electronic, and industrial applications. It ensures reliable access to circuits for troubleshooting without damaging insulation.

Key Features

• Comprehensive 10-Piece Kit: Includes a versatile selection of spoon probes, mini back probes, flexible pins, and shielded alligator clips to address diverse electrical testing requirements.
• Standard 4mm Banana Plug Connectivity: Ensures broad compatibility with existing test leads, multimeters, and oscilloscopes, allowing seamless integration into current diagnostic setups.
• Specialized Back Probes: Features spoon probes for round pin-style connectors, mini back probes for tight access in confined spaces, and flexible back probe pins for reaching difficult-to-access areas without damaging wire insulation.
• Secure Shielded Alligator Clips: Provides reliable and precise connections for stable readings during electrical troubleshooting and circuit analysis.
• Durable Storage Case: Keeps all components organized, protected, and easily accessible, enhancing portability and reducing setup time for field service.

Applications

• Backprobing Electronic Circuits: Ideal for accurate testing of hard-to-access electrical components and connectors in automotive wiring harnesses and control modules.
• Diagnostic Testing: Facilitates the efficient diagnosis of electronic system performance issues, signal integrity, and sensor outputs.
• Electrical Troubleshooting: An indispensable tool for resolving intermittent electrical connection faults, wiring problems, and power distribution issues in various systems.

Specifications

• Manufacturer: Electronic Specialties
• Model Number: 804
• Weight: 1 lbs
• Dimensions: 7 x 5 x 7 inches
• Backprobes Included:
  • 2 pcs Spoon Probe Back Probers for round connectors (#616)
  • 4 pcs Mini Back Probes/Wire Piercers (#618)
  • 2 pcs Flexible Automotive Back Probe Pins (#142-5)
• Alligator Clips Included:
  • 2 pcs Shielded Alligator Clips (#143-1)
• Connector Type: Standard 4mm banana plug
• Storage: Durable case included
