Mastercool | 69390 | MOBILE RECOVERY R1234YF

Specifications

The Mastercool MOBILE RECOVERY R1234YF, model 69390, is a robust refrigerant recovery machine engineered for professional automotive service. It features a 1/2 HP oil-less compressor, operating on a 115V/60 Hz power supply. The unit is designed to operate effectively within a temperature range of 32 to 122°F (0 to 50°C). Constructed with an injection-molded high-density polyethylene (HDPE) case, it offers durability in demanding environments. This recovery machine is compatible with a wide range of refrigerants, including CFCs, HCFCs, HFCs, R-410A, and is approved for A2L and A3 flammable refrigerants. It measures 30 x 30 x 20 inches and weighs 60 lbs. The manufacturer's part number is {manufacturers_part_number}.

Key Features

The Mastercool 69390 is equipped with a spark-free design, making it suitable for handling contaminated R-1234yf mobile A/C systems. Its revolutionary double piston oil-less compressor delivers maximum recovery efficiency. The unit includes an overfill protection switch that automatically cuts off at 80% tank capacity to prevent overfilling. A large fan and condenser work to keep the unit cool, significantly speeding up the recovery process. This machine also features a sealed crankcase to eliminate refrigerant loss during operation and a safety high-pressure cut-off switch for enhanced user protection. Its simple internal structure facilitates easy field service, while built-in bumper guards on the front cover help reduce damage to control knobs.

Applications

This mobile recovery unit is primarily designed for the efficient and safe recovery of R1234yf refrigerant from contaminated mobile A/C systems in automotive workshops and service centers. It is a crucial tool for professionals performing automotive A/C recovery tasks, including those servicing standard and high-voltage vehicle A/C systems. The unit's portability makes it ideal for HVAC technicians working in diverse and mobile environments.

Benefits

The Mastercool 69390 offers a fast recovery time, enhancing operational efficiency for technicians. Its spark-free components ensure safe operation, especially when working with flammable refrigerants, complying with industry safety standards. The large volume recovery rate helps technicians manage demanding jobs effectively. By meeting all requirements of SAE J2851 as a contaminated recovery only device, the unit ensures compliance with important industry standards. The automatic overfill protection switch prevents accidental overfilling, contributing to safer handling of refrigerants. Its durable, high-density polyethylene case and bumper guards provide robust protection, extending the lifespan of the equipment in challenging work conditions. The unit contributes to environmental protection by enabling efficient refrigerant recovery and minimizing waste.
