End Play Check Fixture - Kent-Moore

The Kent-Moore J-24773-A End Play Check Fixture is an essential OEM-specified tool designed for precise axial end play measurement in a variety of automotive and industrial transmission and driveline components. This professional-grade fixture allows technicians to accurately verify clearances against factory specifications, ensuring proper assembly and contributing to the long-term integrity of critical powertrain components.

Key Features

• OEM-Specified Accuracy: Engineered by Kent-Moore to meet stringent factory service requirements, guaranteeing precise measurements and compatibility for designated applications.
• Consistent Axial Measurement: Provides a stable and repeatable setup for accurately checking end play on shafts, gears, and rotating assemblies, featuring a precision-ground anvil and hardened steel plunger.
• Enhanced Repeatability: Dedicated fixture design minimizes setup variations and flex, leading to more reliable and consistent measurement results compared to improvised methods.
• Durable Professional Construction: Built with robust materials to withstand the demands of daily use in busy automotive and industrial workshop environments.
• Supports Correct Assembly: Facilitates confirmation of proper end play before final assembly and torque, mitigating the potential for premature wear, noise, or component failure.

Applications

The Kent-Moore J-24773-A End Play Check Fixture is invaluable for professional technicians servicing:

• Ford Transmissions: Crucial for checking transmission end play on models including F, Y, C/K, S/T, M/L, G/P, 3L80 & HD, and 4L60 transmissions.
• Allison Transmissions: Utilized for checking end play in Allison model AT 540, AT 543, and AT 545 transmissions, and can also assist in pump support assembly removal.
• GM Powertrain Components: Essential for precise axial clearance verification across a wide range of GM vehicles, including specific model years of Buick (Allure, LaCrosse, Lucerne, Rainier), Cadillac (Catera, DTS, Escalade), Chevrolet (Avalanche, Aveo, Camaro, Caprice, Cobalt, Equinox, HHR, Impala, Lumina, Malibu, Silverado, S10 Pickup), Hummer (H3/H3T), Isuzu (Ascender, I-350), Pontiac (Firebird, G6, GTO, Montana SV6, Torrent, Wave), and Saab (9-7x) for transmission and driveline service.

This tool is ideal for engine builders, transmission specialists, and driveline technicians who require consistent, OEM-level measurement accuracy for various powertrain platforms.

Specifications

• Manufacturer: Kent-Moore
• Model Number: J-24773-A
• Product Name: End Play Check Fixture
• Weight: 1 lb
