Replaces part number 7060-21.
No Hoses, No Cords, No HasslesSpecifically designed for use with 600 x 600 ml (1:1) dual component cartridge sets for dispensing adhesives and sealants. Meritool has designed and engineered the PowerPush(TM) 7000 Series, a unique patented battery operated dual component dispenser, which mixes and dispenses efficiently and accurately.
Features and Benefits:- Cordless convenience
- Dual direct drive rack system assures precise mixture control
- Direct planetary gear drive system for reliable operation
- High force capability assures low temperature performance
- Patented design force and speed controlled circuitry to maximize output
- Anti-drip feature eliminates messy run-on
- Dosing on or off control: ensures straight bead application or repeatable shot size (specify at time of order)
- Locking rack release clutch for easy rack retraction
- Includes 14V NiMH battery and charger
DOSING Control Option: This is a Factory Setting and needs to be specified when the order is placed. (Please read below for more information)
Dosing on - allows the user to set the dosing quantity between 3 and 32 seconds (to meet dose requirements/amount for specific application) at which time the tool will automatically stop itself, the racks will reverse slightly. When the tool has fully stopped automatic reverse action - the trigger will need to be pressed again to restart application.
Dosing off - allows for straight bead application the tool will stop when the trigger is released or will automatically stop when the cartridge is fully dispensed.
Technical Specifications:- Capacity: 40oz
- Ratio: 1:1 (600:600ml)
- Weight: 9.3 lbs (4.2 kg)
- Dimensions: 18 x 4 x 13.9" (457 x 101 x 353mm)
- Thrust: Factory set up to 1,800 lbs (8kN)
- Speed: Variable up to 6 in/min (2.5mm/s)
- Battery: 14V NiMH
- Charger: One hour quick charge 110V-240V
Cartridge Compatibility: 1200 ml (1:1) (600 x 600 ml)Dimensions: L: 8.5 in (215 mm) D1: 2.0 in (51 mm) D2: 2.8 in (71 mm)
Meritool PowerPush 7060-V2-11-14V-US Cordless Adhesive Dispenser
