c. 2009 Timing Belt Manual - Autodata Group

Part #: 09-170

Valve Timing Procedures for Domestic and Imported Vehicles 1996-2009

This manual features general removal and installation instructions of timing chains and gears, as well as valve timing procedures for Domestic & Imported Vehicles from 1996 - 2009.

Features:
  • Valve Timing Procedures for Domestic and Imported Vehicles
  • Chain & gear replacement
  • General removal & installation instructions
  • Safety precautions
  • Special tools
  • Tensioner adjustments
  • Tightening torques
  • Timing marks
  • Valve timing instructions
  • Tensioner release & reset methods
  • Chain routing & sprocket/gear valve timing marks
Autodata Publications 09-170 2009 Timing Chains & Gears Manual
Browse Auto Repair Manuals & Charts

This product was added to our catalog on Tuesday 09 June, 2009.
