Mico Filter with 3/4" NPT Metal Bowl

Heavy Duty Metal Bowl Micro Filter 250 PSI

- All micro filters supplied with preassembled Automatic OVERNIGHT DRAIN
- Porous bronze 40 micron filter element allows less pressure drop and longer cleaning intervals
- Safety metal bowl guards
- Metal bowls only on 3/4” and 1” models
- 3 stage baffle system for exceptional moisture removal.
- Sintered bronze elements are permanent and cleanable
- Light weight aluminum die-cast housing
- Element range 10 or 40 microns exactly matching filter and air flow needs
- Corrosion resistant metal bowls
- Includes sight glass for visual check of condensation collection

Warning, For Compressed Air Service Only! Not to be used on life support systems or breathing air systems. Never use polycarbonate plastic bowls on air supplies by a compressor lubricated with synthetic oils or oil containing phosphate esters or chlorinate hydrocarbons. They can carry over into the air distribution systems and chemically attack and possibly rupture the bowls. For these applications use a metal bowl. Materials such as trichloroethylene, acetone, paint thinner or cleaning fluids will craze and/or rupture a polycarbonate bowl. When these materials are present either inside or outside the bowl, use metal bowls. For a more complete list of known harmful chemicals check instruction sheet.

• 3/4” NPT Size
• 10 oz Bowl Capacity
• 250 PSI Max Pressure
• 40-160° F
• 230 Max SCFM
