TUBING FLARING TOOL KIT - ATD Tools

The ATD Tools 5478 Tubing Flaring Tool Kit provides professional technicians and mechanics with the essential equipment for creating precise, leak-resistant flares in critical automotive and industrial fluid systems. This comprehensive kit ensures reliable connections for brake, fuel, and transmission lines, performing effectively in demanding workshop and field environments.

Key Features

• Versatile Flaring Capabilities: Produces SAE 45° single and double flares on 3/16", 1/4", 5/16", 3/8", and 1/2" tubing. It also creates ISO bubble flares for 4.75mm, 6mm, 8mm, and 10mm lines, commonly found on European, Asian, and various domestic vehicle models.
• Precision and Repeatable Results: Engineered with a robust yoke and precision-machined dies to deliver uniform flare geometry, critical for consistent, leak-resistant connections across diverse fluid system applications.
• Integrated Tubing Management: Includes a roller-style tubing bender for smooth, kink-free bends and a compact mini cutter, facilitating clean cuts and access in confined areas such as undercarriages and engine bays.
• Durable, Multi-Material Construction: Built from high-quality materials to withstand the rigors of daily professional use in automotive, HVAC, and industrial settings. It is effective on copper, brass, aluminum, and mild steel tubing.
• Organized and Portable Design: Supplied in a durable, molded case, ensuring secure transport between workstations and job sites while keeping all components protected and organized.

Applications

• Automotive brake line, fuel line, and transmission line fabrication and repair.
• HVAC/R service for creating reliable copper tubing flare connections.
• Light plumbing work requiring precise flared copper lines.
• Industrial maintenance on hydraulic and pneumatic control lines.

Specifications

• Manufacturer: ATD Tools
• Model Number: 5478
• Flare Types: SAE 45° single and double, ISO bubble
• Weight: 6.115 lb
• Dimensions: 13.1" x 10.3" x 2.55"
