Whisper Ultrasonic Leak Detector

Whisper Ultrasonic Leak Detector allows the user to check for pressure and vacuum leaks where other sniffer style leak detectors can`t go. With the unique internal noise control circuitry, the technician can operate Whisper in high noise environments. The ergonomic design gives the user the convenience of one-hand operation and carries a two-year replacement warranty.

INFICON Whisper Ultrasonic Leak Detector is ideal for detecting and locating sources of ultrasonic sound through the use of sophisticated electronic circuitry.

Unaffected by audible noise, Whisper incorporates an Internal Noise Control allowing for use in extremely noisy environments, such as mechanical rooms, and around operating chillers.

Because Whisper is designed to detect ultrasound at 40.5 kHz, not even a murmur will escape detection.

Use the optional transmitter for quick and accurate leak checking in walk-in coolers / freezers, wall and ceiling joints, around doors, windows, ducts, etc.

Applications at a glance:

• Refrigerant Leaks
• Locating Worn Bearings
• Leaks in Pneumatic Control Systems
• Leaks in Natural Gas, LPG Leaks
• Leaks in Compressed Air Systems
• Leaks in Vacuum Systems
• Butane / Propane Storage Tank Leaks
• Line Set Leaks in Foundations / Walls
• Diagnosing Solenoid Operations
• Steam Traps
• Electrical Arcing

Specifications:

Base unit includes 9 V battery, rubber probe extension, headphones and storage case.

Controls On / Off switch, Sensitivity: maximum/minimum knob

Power One 9 volt alkaline battery

Weight with battery 9 oz (0.25 kg)

Operating temperature range 32° to +122°; 0° to +50°

Storage Temperature 14° to +140°; -10° to +60°

Warranty 2 years
