M7 3/4" Drive Composite Air Impact Wrench , New Twin Hammer 1200 - Horizon Tool, Inc

The Horizon Tool, Inc. M7 3/4" Drive Composite Air Impact Wrench, model NC-6216, delivers robust performance for professional automotive and industrial applications. Engineered with a new Twin Hammer mechanism, this impact wrench provides 1200 ft-lb of maximum torque and a free speed of 6000 RPM, making it ideal for efficient fastening and loosening of stubborn bolts. Its composite construction contributes to a lighter tool, enhancing user comfort during prolonged use.

Key Features

• Powerful Twin Hammer Mechanism: The new Twin Hammer impact mechanism is designed to increase both durability and efficiency, delivering consistent high torque output.
• High Torque Output: Achieves a maximum torque of 1200 ft-lb (1627 Nm) for demanding tasks, with a working torque range of 200-1000 ft-lb (271-1356 Nm).
• Optimized Speed: Features a free speed of 6000 RPM, allowing for rapid fastening and removal of components.
• Integrated Control: A multi-function switch allows for simultaneous control of forward/reverse direction and speed.
• Durable Composite Housing: The composite body reduces tool weight to 9.0 lbs (4.1 kg), minimizing operator fatigue while maintaining robust professional-grade construction.
• Reduced Vibration: The Twin Hammer impact clutch also contributes to less vibration, allowing for extended work periods.

Applications

This M7 3/4" Drive Composite Air Impact Wrench is suitable for a range of heavy-duty applications. It excels in automotive repair and maintenance, including tire service, engine work, and transmission tasks on trucks, trailers, and buses. Additionally, its high torque capability makes it essential for heavy equipment maintenance, such as agricultural machinery and construction equipment, as well as general industrial manufacturing and assembly operations where large fasteners are common.

Specifications

• Square Drive: 3/4"
• Bolt Capacity: 1-1/16" (27 mm)
• Torque Range: 200-1000 FT-LB (271-1356 Nm)
• Max Torque: 1200 FT-LB (1627 Nm)
• Free Speed R.P.M.: 6000
• Avg. Air Consumption: 6.0 CFM (170 L/min)
• Air Pressure: 90 PSI (6.3 bar)
• Overall Length: 9-1/4" (235 mm)
• Net Weight: 9.0 LBS (4.1 kg)
• Air Hose: 1/2"
• Sound Pressure EN ISO 15744: 91.2 dBA
• Vibration Level: 5.0 m/s²
