1/4 In Dr Dial Indicating Drive - Precision Instruments

Specifications

The Precision Instruments DS1F48CZHM is a 1/4 inch drive dial indicating drive. This tool is manufactured by Precision Instruments and features a square drive size of 1/4 inch. It operates within a capacity range of 0-3 in-lbs (0-48 In/Oz), with primary scale increments of 1 oz.in. and secondary scale increments of 0.0625 lbs-in. The drive is accurate to 2% of the reading from 20% of full scale to full scale, both clockwise and counterclockwise. The product weighs 1.8 lbs and has dimensions of 9.5 x 5 x 3 inches. It meets or exceeds applicable standards including ANSI / ASME B107.14M, GGG-W-00686C, BS6073: 1988, and ISO6789.

Key Features

• 1/4 Inch Square Drive: Designed for compatibility with a wide array of standard 1/4 inch sockets and accessories.
• Dial Indicating Mechanism: Provides direct, real-time torque readings on an easy-to-read dial, simplifying the measurement process.
• Hand-Hold Insensitivity: Engineered to maintain accuracy regardless of the hand position on the drive, eliminating potential measurement errors.
• Torsion Bar Design: Features an exclusive torsion bar design with a direct connection from the square drive to the dial, ensuring reliable and precise measurements.
• Compact Construction: Its compact design and tapered nose facilitate ease of operation and provide clearance in confined working environments.

Applications

The Precision Instruments DS1F48CZHM is suited for precise torque application across various professional fields. It is particularly effective in delicate applications such as fastening fuel injectors and components made from plastics, where strict tolerances are crucial. This dial indicating drive is also utilized in automotive repair and assembly, aerospace manufacturing and maintenance, and for quality control checks requiring exact fastening. Furthermore, it finds use in industrial settings for equipment installation and calibration, and for any tasks demanding high-precision torque measurement.

Benefits

• Ensures Accuracy: Delivers precise torque specifications with 2% accuracy, preventing both over-tightening and under-tightening of fasteners, thereby enhancing component integrity.
• Improves Reliability: The consistent and accurate performance contributes to increased operational safety and the long-term reliability of assembled components.
• Reduces Damage: By facilitating exact torque application, the tool helps to mitigate material fatigue and prevent damage to delicate components.
• Streamlines Compliance: Aids in adhering to stringent industry standards and specifications, supported by compliance with ANSI / ASME B107.14M and ISO6789.
• Enhances Efficiency: Offers immediate and clear torque readings, which simplifies the measurement process and contributes to more efficient assembly and quality control operations.
